The AVEVA E3D (Everything 3D) Training Manual is a structured, modular guide designed to teach users how to use AVEVA’s next-generation 3D design software for plant and marine industries. It’s widely used in mechanical, piping, structural, and electrical design disciplines.

Volume I: Equipment Modeling

Introduction to primitive and parametric equipment
Creating standard vessels, pumps, tanks
Modifying and placing equipment in 3D space

Volume II: Piping Design

Pipe routing using specifications
Component placement (elbows, tees, valves, etc.)
Branching, insulation, supports, and nozzle connection

Volume III: Structural Modeling

Beam, column, and frame modeling
Staircase and platform design
Structural member library usage

Volume IV: Electrical & Cable Tray

Creating cable trays and supports
Modeling electrical equipment
Cable routing basics

Volume V: HVAC Modeling

Duct routing and components
AHU and HVAC unit modeling
HVAC system integration with structure

Volume VI: Hangers and Supports

Pipe support templates and placement
Rack support systems
Adjusting supports for clashes and real-world constraints

Volume VII: Report Generation

Generating Material Take-Off (MTO) reports
BOM creation
Exporting reports to Excel/PDF

Volume VIII: Isometric & Spool Drawings

Generating automatic isometrics
Creating spools and weld maps
Exporting in DWG/DXF/DGN formats

Volume IX: Drawing Manager

2D view generation from 3D models
Sheet layout and view creation
Annotation, layering, and dimensions

Volume X: Admin & Commands

Clash checking and resolution
Hole management
Exporting/importing model databas
